CUTTING TOOLS
Fluteless Machine Taps with Oil Groove DIN371/376 -HSS-E- Tol.ISO2X/6HX or Tol.ISO3X/6GX and TIN or VAP
Ref : 356
for chipless production of internal threads /Advantages:
- longer endurance as cutting taps
- higher possible cutting speed
- steady exactness of dimension and profile
- high stability of the forming threads
- high security against fracture
- no removal of swarf.Application:
- for nonferrous metal of good ductility
- unalloyed and low alloyed steel
- Structural Steel
- heat resistant steel
- stainless steel
- for long
-chipping nonferrous Metal (Cooper, Brass, Bronze, Alu)
- Zinc alloys
- for through and blind holesOil Groove:
- for optimueffect of lubrication of thread depth over 1,5 x D
- Use graphite lubrication/oil or add another suitable lubricant.
- longer endurance as cutting taps
- higher possible cutting speed
- steady exactness of dimension and profile
- high stability of the forming threads
- high security against fracture
- no removal of swarf.Application:
- for nonferrous metal of good ductility
- unalloyed and low alloyed steel
- Structural Steel
- heat resistant steel
- stainless steel
- for long
-chipping nonferrous Metal (Cooper, Brass, Bronze, Alu)
- Zinc alloys
- for through and blind holesOil Groove:
- for optimueffect of lubrication of thread depth over 1,5 x D
- Use graphite lubrication/oil or add another suitable lubricant.
| DIN 371/376 | |
| Coolant flute | |
| Metric thread | |
| Right hand thread |
| Matter | Type |
|---|---|
| STEELS |
REFRACTORY – NICKEL
FERRITIC STAINLESS 700 N/mm2
from 1000 to 1300N/mm2
|
| ALUMINUM |
> 6% of Silicium
|
| COPPER – BRASS |
YES
|
| BRONZE |
YES
|
LOG IN TO ACCESS YOUR ACCOUNT
| Designation | Ø tools | Ø tail d2 | Useful length |
Total length |
Stock | Price | |
|---|---|---|---|---|---|---|---|
| 35610 M3 Fluteless Taps With oil groove | M 3 x 0.5 | 3.5 | 11 | 56 | 2.7 | / | 11,30 € |
| 35610-6G M3 Fluteless Tap + oil groove 6GX | M 3 x 0.5 | 3.5 | 11 | 56 | 2.7 | 2 | 12,20 € |
| 35612 M4 Fluteless Taps With oil groove | M 4 x 0.7 | 4.5 | 13 | 63 | 3.4 | / | 12,80 € |
| 35612-6G M4 Fluteless Tap + oil groove 6GX | M 4 x 0.7 | 4.5 | 13 | 63 | 3.4 | / | 13,60 € |
| 35613 M5 Fluteless Taps With oil groove | M 5 x 0.8 | 6 | 16 | 70 | 4.9 | / | 14,10 € |
| 35613-6G M5 Fluteless Tap + oil groove 6GX | M 5 x 0.8 | 6 | 16 | 70 | 4.9 | 1 | 14,80 € |
| 35614 M6 Fluteless Taps With oil groove | M 6 x 1.0 | 6 | 19 | 80 | 4.9 | / | 14,10 € |
| 35614-6G M6 Fluteless Tap + oil groove 6GX | M 6 x 1.0 | 6 | 19 | 80 | 4.9 | / | 14,80 € |
| 35615 M8 Fluteless Taps With oil groove | M 8 x 1.25 | 8 | 22 | 90 | 6.2 | / | 17,00 € |
| 35615-6G M8 Fluteless Tap + oil groove 6GX | M 8 x 1.25 | 8 | 22 | 90 | 6.2 | / | 18,00 € |
| 35616 M10 Fluteless Taps With oil groove | M 10 x 1.5 | 10 | 24 | 100 | 8.0 | / | 19,90 € |
| 35616-6G M10 Fluteless Tap + oil groove 6GX | M 10 x 1.5 | 10 | 24 | 100 | 8.0 | 11 | 20,90 € |
| 35617 M12 Fluteless Taps With oil groove | M 12 x 1.75 | 9 | 29 | 110 | 7.0 | 2 | 25,50 € |
| 35617-6G M12 Fluteless Tap + oil groove 6GX | M 12 X 1.75 | 9 | 29 | 110 | 7.0 | 1 | 26,80 € |
| 35618 M14 Fluteless Tap with oil groove | M 14 x 2.0 | 11 | 30 | 110 | 9.0 | / | 42,80 € |
| 35619 M16 Fluteless Tap with oil groove | M 16 x 2.0 | 12 | 32 | 110 | 9.0 | 1 | 51,40 € |
| 35630 M3 Fluteless Tap with oil groove-TIN | M 3 x 0.5 | 3.5 | 11 | 56 | 2.7 | / | 14,80 € |
| 35632 M4 Fluteless Tap with oil groove-TIN | M 4 x 0.7 | 4.5 | 13 | 63 | 3.4 | / | 16,30 € |
| 35633 M5 Fluteless Tap with oil groove-TIN | M 5 x 0.8 | 6 | 16 | 70 | 4.9 | / | 17,60 € |
| 35634 M6 Fluteless Tap with oil groove-TIN | M 6 x 1.0 | 6 | 19 | 80 | 4.9 | / | 18,10 € |
| 35635 M8 Fluteless Tap with oil groove-TIN | M 8 x 1.25 | 8 | 22 | 90 | 6.2 | / | 22,00 € |
| 35636 M10 Fluteless Tap with oil groove-TIN | M 10 x 1.5 | 10 | 24 | 100 | 8.0 | / | 26,40 € |
| 35637 M12 Fluteless Tap with oil groove-TIN | M 12 x 1.75 | 9 | 29 | 110 | 7.0 | / | 35,50 € |
| 35638 M14 Fluteless Tap with oil groove-TIN | M 14 x 2.0 | 11 | 30 | 110 | 9.0 | / | 53,80 € |
| 35639 M16 Fluteless Tap with oil groove-TIN | M 16 x 2.0 | 12 | 32 | 110 | 9.0 | / | 63,40 € |
| 35650 M3 Fluteless Tap with oil groove-VAP | M 3 x 0.5 | 3.5 | 11 | 56 | 2.7 | / | 12,40 € |
| 35652 M4 Fluteless Tap with oil groove-VAP | M 4 x 0.7 | 4.5 | 13 | 63 | 3.4 | / | 14,10 € |
| 35653 M5 Fluteless Tap with oil groove-VAP | M 5 x 0.8 | 6 | 16 | 70 | 4.9 | / | 15,50 € |
| 35654 M6 Fluteless Tap with oil groove-VAP | M 6 x 1.0 | 6 | 19 | 80 | 4.9 | / | 15,50 € |
| 35655 M8 Fluteless Tap with oil groove-VAP | M 8 x 1.25 | 8 | 22 | 90 | 6.2 | / | 18,70 € |
| 35656 M10 Fluteless Tap with oil groove-VAP | M 10 x 1.5 | 10 | 24 | 100 | 8.0 | 1 | 21,90 € |
| 35657 M12 Fluteless Tap with oil groove-VAP | M 12 x 1.75 | 9 | 29 | 110 | 7.0 | / | 28,10 € |
| 35658 M14 Fluteless Tap with oil groove-VAP | M 14 x 2.0 | 11 | 30 | 110 | 9.0 | / | 47,10 € |
| 35659 M16 Fluteless Tap with oil groove-VAP | M 16 x 2.0 | 12 | 32 | 110 | 9.0 | / | 56,50 € |
DELIVERY DELAY
For the products out of stock, please contact us
